ETERN Optoelectronics XFP CWDM 40km Optical Transceiver
The ETERN Optoelectronics XFP CWDM 40km series provides high-performance, cost-effective solutions for Coarse Wavelength Division Multiplexing. Supporting data rates from 9.9Gbps to 11.3Gbps, these transceivers are compliant with XFP MSA and IEEE 802.3ae protocols, optimized for 10G Ethernet, SDH/SONET, and OTN infrastructures.
Key Technical Highlights
- Standard Compliance: Fully compliant with 10GBASE-ER/EW and 10GBASE-ZR/ZW standards.
- Optical Versatility: Equipped with EML Transmitters and the choice of PIN or APD receivers for varied link budgets.
- CWDM Spectrum: Supports C47 to C61 wavelength ranges for efficient multi-channel integration.
- Operating Temperature: Available in Commercial (0°C~70°C) and Industrial (-40°C~85°C) options.
Full Product Specifications Comparison
For detailed technical data and ordering information, please contact sales@szetern.com.
| Parameter | Model A (PIN-COM) | Model B (PIN-IND) | Model C (APD-COM) | Model D (APD-IND) |
|---|---|---|---|---|
| Part Number | FLS10C642S-C47~C61 | FLS10I642S-C47~C61 | FLS10C682S-C47~C61 | FLS10I682S-C47~C61 |
| Package | XFP | XFP | XFP | XFP |
| Data Rate | 10G | 10G | 10G | 10G |
| Wavelength | CWDM | CWDM | CWDM | CWDM |
| Reach | 40KM | 40KM | 40KM | 40KM |
| Transmitter | EML | EML | EML | EML |
| Receiver | PIN | PIN | APD | APD |
| TX output (dBm) | 2~-2 | 2~-2 | 4~0 | 4~0 |
| RX Sensitivity (dBm) | -16 | -16 | -23 | -23 |
| Power Consumption (W) | <3.5 | <3.5 | <3.5 | <3.5 |
| Interface | LC | LC | LC | LC |
| Temperature | 0°C~70°C | -40°C~85°C | 0°C~70°C | -40°C~85°C |
| Application | 10GBASE-ER/EW | 10GBASE-ER/EW | 10GBASE-ZR/ZW | 10GBASE-ZR/ZW |
