ETERN Optoelectronics SFP+ Series Optical Transceiver
ETERN Optoelectronics provides high-performance, cost-effective SFP+ transceivers designed for 10Gbps data transmission. Fully compliant with SFP+ MSA and SFF-8472 protocols, our modules cover rates from 1Gbps to 10Gbps. With options for both commercial (0°C to 70°C) and industrial (-40°C to 85°C) temperature ranges, these transceivers are the ideal choice for 10G Ethernet, 10G Fibre Channel, SDH/SONET, OTN, and CPRI/OBSAI wireless front-haul scenarios.
Key Features
- Broad Application Range: Optimized for 10G Ethernet, 32GFC, and CPRI/OBSAI.
- Flexible Distances: Reach options from 300m (SR) to 80km (ZR).
- High Reliability: Supports Digital Diagnostic Monitoring (DDM) for real-time performance tracking.
- Advanced Laser Tech: Utilizes VCSEL, FP, DFB, or EML transmitters to meet diverse link requirements.
Technical Specifications (Product List)
More products / specifications, welcome to contact sales at sales@szetern.com.
Table 1: SFP+ SR, 6G, and 10G LR/LW Series
| Part Number | Package | Data Rate | Wavelength | Reach | Transmitter | Receiver | TX output | RX Sensitivity | Power | Interface | Temperature | Application |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FLS10C030S | SFP+ | 10G | 850nm | 300M | VCSEL | PIN | 0.5~-6 | -10 | <1 | LC | 0℃~70℃ | 10GBASE-SR/SW |
| FLS10C050S | SFP+ | 10G | 850nm | 300M | VCSEL | PIN | 0.5~-6 | -10 | <1 | LC | 0℃~70℃ | 10GBASE-SR/SW |
| FLS06C110S | SFP+ | 6G | 1310nm | 2KM | FP | PIN | 2~-6 | -14.4 | <1 | LC | 0℃~70℃ | CPRI/OBSAI |
| FLS06I110S | SFP+ | 6G | 1310nm | 2KM | FP | PIN | 2~-6 | -14.4 | <1 | LC | -40℃~85℃ | CPRI/OBSAI |
| FLS10C102S | SFP+ | 10G | 1310nm | 2KM | FP | PIN | 2~-6 | -14.4 | <1 | LC | 0℃~70℃ | 10GBASE-LR/LW |
| FLS10I102S | SFP+ | 10G | 1310nm | 2KM | FP | PIN | 2~-6 | -14.4 | <1 | LC | -40℃~85℃ | 10GBASE-LR/LW |
| FLS10C110S | SFP+ | 10G | 1310nm | 10KM | DFB | PIN | 2~-6 | -14.4 | <1 | LC | 0℃~70℃ | 10GBASE-LR/LW |
| FLS10I110S | SFP+ | 10G | 1310nm | 10KM | DFB | PIN | 2~-6 | -14.4 | <1 | LC | -40℃~85℃ | 10GBASE-LR/LW |
| FLS10C112S | SFP+ | 10G | 1310nm | 20KM | DFB | PIN | 2~-6 | -15 | <1 | LC | 0℃~70℃ | 10GBASE-LR/LW |
| FLS10I112S | SFP+ | 10G | 1310nm | 20KM | DFB | PIN | 2~-6 | -15 | <1 | LC | -40℃~85℃ | 10GBASE-LR/LW |
Table 2: SFP+ ER and ZR Series (40KM / 80KM with CDR options)
| Part Number | Package | Data Rate | Wavelength | Reach | Transmitter | Receiver | TX output | RX Sensitivity | Power | Interface | Temperature | Application |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FLS10C113S | SFP+ | 10G | 1310nm | 40KM | DFB | PIN | 5~0 | -15 | <1 | LC | 0℃~70℃ | 10GBASE-ER/EW |
| FLS10I113S | SFP+ | 10G | 1310nm | 40KM | DFB | PIN | 5~0 | -15 | <1 | LC | -40℃~85℃ | 10GBASE-ER/EW |
| FLS10C240S | SFP+ | 10G | 1550nm | 40KM | EML | PIN | 2~-2 | -16 | <1.5 | LC | 0℃~70℃ | 10GBASE-ER/EW |
| FLS10I240S | SFP+ | 10G | 1550nm | 40KM | EML | PIN | 2~-2 | -16 | <1.8 | LC | -40℃~85℃ | 10GBASE-ER/EW |
| FLS10C243S | SFP+ | 10G | 1550nm | 40KM | EML | PIN | 2~-2 | -16 | <1.8 | LC | 0℃~70℃ | 10GBASE-ER/EW CDR |
| FLS10I243S | SFP+ | 10G | 1550nm | 40KM | EML | PIN | 2~-2 | -16 | <2 | LC | -40℃~85℃ | 10GBASE-ER/EW CDR |
| FLS10C280S | SFP+ | 10G | 1550nm | 80KM | EML | APD | 4~0 | -23 | <1.8 | LC | 0℃~70℃ | 10GBASE-ZR/ZW |
| FLS10I280S | SFP+ | 10G | 1550nm | 80KM | EML | APD | 4~0 | -23 | <2 | LC | -40℃~85℃ | 10GBASE-ZR/ZW |
| FLS10C283S | SFP+ | 10G | 1550nm | 80KM | EML | APD | 4~0 | -23 | <2.3 | LC | 0℃~70℃ | 10GBASE-ZR/ZW CDR |
| FLS10I283S | SFP+ | 10G | 1550nm | 80KM | EML | APD | 4~0 | -23 | <2.5 | LC | -40℃~85℃ | 10GBASE-ZR/ZW CDR |
