Overview
We provide high-performance optical components, including advanced optical filters (longpass, shortpass, and bandpass), premium lenses, and sub-assemblies. These precise components are widely utilized in biomedical devices and clinical equipment demanding strict wavelength control.
Target Applications: Polymerase Chain Reaction (PCR) / Flow Cytometry / DNA Sequencers / Endoscopic Systems / Spectroscopy / Biomedical Imaging / Colorimetry / Microscopy / Blood Analysis / Raman Spectrometers
Performance Characteristics for Excitation & Emission Filters
- High Transmittance: > 95% for maximum signal throughput.
- Angle of Incidence (AOI): Optimally calibrated at 0° - 5°.
- Deep Out-of-Band Blocking: Depth cut-off < 0.5% (achieving OD 4 - OD 6 within the detector spectrum range) for high signal-to-noise ratios.
Performance Characteristics for Dichroic Filters
- High Transmittance: > 95% pass-band transmission efficiency.
- Excellent Reflection Rate: 97% reflection efficiency for target wavelengths.
- Angle of Incidence (AOI): 45° ± 2° for standard instrumentation setups.
- Precision Depth Cut-off: Transition zone depth cut-off < 1%, with ultra-deep blocking of < 0.5% (OD 4 - OD 6 in the detector range).
