ETERN Optoelectronics 100G QSFP28 LR1 10km Optical Transceiver
The FLS100C303S is a high-performance 100Gb/s QSFP28 LR1 optical transceiver designed for 10km single-mode fiber (SMF) links using advanced Single-Lambda PAM4 technology.
Engineered for modern data center interconnects, this module supports 100G Ethernet applications compliant with the IEEE 802.3cu 100GBASE-LR1 standard. The transceiver utilizes an innovative design that converts 4x 25G NRZ electrical signals into a single 100G PAM4 optical signal at the transmission side, and vice-versa at the receiver. By reducing the optical components to a single wavelength (1310nm), it provides a cost-effective and power-efficient solution for long-distance connectivity up to 10km, featuring an EML transmitter and PIN receiver for superior link stability.
Key Technical Highlights
- Single-Lambda PAM4: Optimized 100G transmission over a single wavelength, reducing complexity and operational costs.
- 10km Reach over SMF: Reliable long-distance transmission via 1310nm EML laser technology and LC duplex connectivity.
- Low Power Consumption: Advanced DSP integration ensures total power consumption is kept below 4W.
- Broad Compatibility: Fully compliant with QSFP28 MSA and IEEE 802.3cu standards for seamless network integration.
Applications
The ideal choice for 100GBASE-LR Ethernet links, enterprise core networking, and high-bandwidth data center interconnects (DCI) up to 10km.
Product List & Detailed Specifications
For technical datasheets or bulk inquiries, please contact sales@szetern.com.
